DSP4.1V3

4 x 75Watts  +  1 x 300Watts
Digital Signal Processor

To experience the sensations of a precise but controlled and stable sound in your car.
Create the type of architecture you’re looking for, the audio processing chain can be optimized with digital signal processing and one or more amplifiers.

POWER SUPPLY
Voltage :  8.5 – 15VDC
Idling Current :  1.5A
Switched off without DRC :  2.5mA
Switched off with DRC :  4mA
Remote IN voltage :  7 – 15VDC (1.3mA)
Remote OUT voltage :  12VDC (130mA)
SIGNAL STAGE
Distortion – THD @ 1KHz, 1V RMS Output :  0.01%
Bandwidth @ -3dB :  10 – 20KHz
S/N ratio Full Power A- :  90dBA
High Level Input Range :  3 – 15V
THD+N VS Power 1% :
 4 x 75W + 300W

INPUT STAGE
High Level (Speaker) :  FL-FR-RL-RR-SUBL-SUBR

CONNECTION
From/To Personal Computer :  1 x USB/B (1.1/2.0) 5M

CROSSOVER (one each output channel)
Filter Type :  Full/High/Low Pass/Band Pass
Slope Setting :  6/12/18/24/30/42/48 dB
Crossover Frequency :  68steps @ 20 – 20KHz
Phase control independent setting :
 0 – 180° each channel
